Husqvarna 550 XP® Mark II Gas Chainsaw (18" SN .325" 1,3 mm SP33G | SKU: 967 69 08‑38)
Best in class cutting capacity.
| Engine |
16" SN .325" 1,5 mm S35G
SKU: 967 69 08‑16
|
18" SN .325" 1,5 mm S35G
SKU: 967 69 08‑18
|
20" SN .325" 1,5 mm S35G
SKU: 967 69 08‑20
|
16" SN .325" 1,3 mm SP33G
SKU: 967 69 08‑36
|
18" SN .325" 1,3 mm SP33G
SKU: 967 69 08‑38
|
20" SN .325" 1,3 mm SP33G
SKU: 967 69 08‑50
|
| Chain speed at max power | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts | 64.3 fts |
|---|---|---|---|---|---|---|
| Cylinder displacement | 3.06 cu.inch | 3.06 cu.inch | 3.06 cu.inch | 3.06 cu.inch | 3.06 cu.inch | 3.06 cu.inch |
|
Power output
|
4 hp | 4 hp | 4 hp | 4 hp | 4 hp | 4 hp |
| Torque, max. | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm | 3.15 Nm |
| Torque, max. at rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm | 7,800 rpm |
| Clutch engagement speed (±120) | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm |
| Electrode gap | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in |
| Idling speed | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm |
| Ignition module air gap | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in |
| Maximum power speed | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm |
| Oil pump type | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle |
| Spark Plug | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H |
| Equipment | ||||||
| Recommended bar length, min | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in |
| Pitch | .325" | .325" | .325" | .325" | .325" | .325" |
| Recommended bar length, max | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in |
| Chain type | S35G | S35G | S35G | SP33G | SP33G | SP33G |
| Bar length | 40 cm | 45 cm | 50 cm | 40 cm | 45 cm | 50 cm |
| Bar length (inch) | 16 in | 18 in | 20 in | 16 in | 18 in | 20 in |
| Sprocket type | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 |
| Gauge | .058" | .058" | .058" | .050" | ||
| Dimensions | ||||||
| Weight (excl. cutting equipment) | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs |
| Sound and noise | ||||||
| Sound pressure level at operators ear | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) | 107 dB(A) |
| Sound power level, guaranteed (LWA) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) |
| Sound power level, measured | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) |
| Vibration | ||||||
| Equivalent vibration level (ahv, eq) rear handle | 4.9 m/s² | 4.9 m/s² | 4.9 m/s² | 4.9 m/s² | 4.9 m/s² | 4.9 m/s² |
| Equivalent vibration level (ahv, eq) front handle | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² |
| Lubricant | ||||||
| Oil tank volume | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
| Emission | ||||||
|
Exhaust emissions (CO₂ EU V)
|
813 g/kWh | 813 g/kWh | 813 g/kWh | 813 g/kWh | 813 g/kWh | 813 g/kWh |
Engine
Chain speed at max power
64.3 fts
64.3 fts
64.3 fts
64.3 fts
64.3 fts
64.3 fts
Cylinder displacement
3.06 cu.inch
3.06 cu.inch
3.06 cu.inch
3.06 cu.inch
3.06 cu.inch
3.06 cu.inch
4 hp
4 hp
4 hp
4 hp
4 hp
4 hp
Torque, max.
3.15 Nm
3.15 Nm
3.15 Nm
3.15 Nm
3.15 Nm
3.15 Nm
Torque, max. at rpm
7,800 rpm
7,800 rpm
7,800 rpm
7,800 rpm
7,800 rpm
7,800 rpm
Clutch engagement speed (±120)
3,900 rpm
3,900 rpm
3,900 rpm
3,900 rpm
3,900 rpm
3,900 rpm
Electrode gap
0.02 in
0.02 in
0.02 in
0.02 in
0.02 in
0.02 in
Idling speed
2,800 rpm
2,800 rpm
2,800 rpm
2,800 rpm
2,800 rpm
2,800 rpm
Ignition module air gap
0.01 in
0.01 in
0.01 in
0.01 in
0.01 in
0.01 in
Maximum power speed
10,200 rpm
10,200 rpm
10,200 rpm
10,200 rpm
10,200 rpm
10,200 rpm
Oil pump type
Adjustable flow, no flow at idle
Adjustable flow, no flow at idle
Adjustable flow, no flow at idle
Adjustable flow, no flow at idle
Adjustable flow, no flow at idle
Adjustable flow, no flow at idle
Spark Plug
NGK CMR6H
NGK CMR6H
NGK CMR6H
NGK CMR6H
NGK CMR6H
NGK CMR6H
Equipment
Recommended bar length, min
13 in
13 in
13 in
13 in
13 in
13 in
Pitch
.325"
.325"
.325"
.325"
.325"
.325"
Recommended bar length, max
20 in
20 in
20 in
20 in
20 in
20 in
Chain type
S35G
S35G
S35G
SP33G
SP33G
SP33G
Bar length
40 cm
45 cm
50 cm
40 cm
45 cm
50 cm
Bar length (inch)
16 in
18 in
20 in
16 in
18 in
20 in
Sprocket type
Rim 7
Rim 7
Rim 7
Rim 7
Rim 7
Rim 7
Gauge
.058"
.058"
.058"
.050"
Dimensions
Weight (excl. cutting equipment)
11.7 lbs
11.7 lbs
11.7 lbs
11.7 lbs
11.7 lbs
11.7 lbs
Sound and noise
Sound pressure level at operators ear
107 dB(A)
107 dB(A)
107 dB(A)
107 dB(A)
107 dB(A)
107 dB(A)
Sound power level, guaranteed (LWA)
117 dB(A)
117 dB(A)
117 dB(A)
117 dB(A)
117 dB(A)
117 dB(A)
Sound power level, measured
115 dB(A)
115 dB(A)
115 dB(A)
115 dB(A)
115 dB(A)
115 dB(A)
Vibration
Equivalent vibration level (ahv, eq) rear handle
4.9 m/s²
4.9 m/s²
4.9 m/s²
4.9 m/s²
4.9 m/s²
4.9 m/s²
Equivalent vibration level (ahv, eq) front handle
4 m/s²
4 m/s²
4 m/s²
4 m/s²
4 m/s²
4 m/s²
Lubricant
Oil tank volume
0.68 US pint
0.68 US pint
0.68 US pint
0.68 US pint
0.68 US pint
0.68 US pint
Lubricant type (Engine)
Husqvarna 2 stroke or equiv. at 50:1
Husqvarna 2 stroke or equiv. at 50:1
Husqvarna 2 stroke or equiv. at 50:1
Husqvarna 2 stroke or equiv. at 50:1
Husqvarna 2 stroke or equiv. at 50:1
Husqvarna 2 stroke or equiv. at 50:1
Emission
813 g/kWh
813 g/kWh
813 g/kWh
813 g/kWh
813
