19' SCISSOR LIFT
Work Height | 24’ 6” (7.47 m) |
Raised Platform Height | 18’ 6” (5.64 m) |
Lowered Platform Height | 41” (1.04 m) |
Overall Width | 32” (0.81 m) |
Overall Length | 71” (1.80 m) |
Stowed Height (Rails Up) | 84” (2.13 m) |
Stowed Height (Rails Down) | 79.75” (2.02 m) |
Platform Width (Inside Dimension) | 26” (0.66 m) |
Platform Length (Inside Dimension) | 61” (1.55 m) |
Extension Deck (Roll Out) | 3’ (0.91 m) |
Ground Clearance (Stowed) | 3.5” (8.9 cm) |
Ground Clearance (raised) | 0.50” (1.3 cm) |
Wheelbase | 54” (1.37 m) |
Weight | 3,255 lbs (1,476 kg) |
Gradeability | 25% |
Turning Radius (Inside) | 0 |
Turning Radius (Outside) | 65” (1.65 m) |
Lift Time (With Rated Load) | 19 sec |
Lower Time (With Rated Load) | 25 sec |
Drive Speed (Stowed) | 2.1 mph (3.4 km/h) |
Drive Speed (Raised) | 0.7 mph (1.1 km/h) |
Maximum Drive Height | Full Height |
Capacity | 500 lbs (227 kg) |
Distributed Capacity (Main Platform) | 250 lbs (113 kg) |
Distributed Capacity (Extension Deck) | 250 lbs (113 kg) |
Local Floor Load (With Rated Load) | 168 psi (1,159 kPa) |
Overall Floor Load (With Rated Load) | 243 psf (1,188 kg/m2) |
Maximum # of Persons | 2 |
Tire Type | Solid, N/M |
Tire Size | 12 x 4 x 8 |
Raised Platform Height | 18’ 6” (5.64 m) |
Lowered Platform Height | 41” (1.04 m) |
Overall Width | 32” (0.81 m) |
Overall Length | 71” (1.80 m) |
Stowed Height (Rails Up) | 84” (2.13 m) |
Stowed Height (Rails Down) | 79.75” (2.02 m) |
Platform Width (Inside Dimension) | 26” (0.66 m) |
Platform Length (Inside Dimension) | 61” (1.55 m) |
Extension Deck (Roll Out) | 3’ (0.91 m) |
Ground Clearance (Stowed) | 3.5” (8.9 cm) |
Ground Clearance (raised) | 0.50” (1.3 cm) |
Wheelbase | 54” (1.37 m) |
Weight | 3,255 lbs (1,476 kg) |
Gradeability | 25% |
Turning Radius (Inside) | 0 |
Turning Radius (Outside) | 65” (1.65 m) |
Lift Time (With Rated Load) | 19 sec |
Lower Time (With Rated Load) | 25 sec |
Drive Speed (Stowed) | 2.1 mph (3.4 km/h) |
Drive Speed (Raised) | 0.7 mph (1.1 km/h) |
Maximum Drive Height | Full Height |
Capacity | 500 lbs (227 kg) |
Distributed Capacity (Main Platform) | 250 lbs (113 kg) |
Distributed Capacity (Extension Deck) | 250 lbs (113 kg) |
Local Floor Load (With Rated Load) | 168 psi (1,159 kPa) |
Overall Floor Load (With Rated Load) | 243 psf (1,188 kg/m2) |
Maximum # of Persons | 2 |
Tire Type | Solid, N/M |
Tire Size | 12 x 4 x 8 |
Skyjack electric scissor lifts have been recognized as an industry leader for over a decade. Our DC scissor lifts are ideal for indoor work where accuracy and precision turns around sensitive material is critical. A proven and reliable control system, incorporating Skyjack's color coded and numbered wiring system, make our machines the easiest to trouble shoot d repair which means easier maintenance and lowered costs. Low voltage battery protection. 25% Gradeability. Solid rubber, non-marking tires. 28 Mph (12.5 m/s) Wind rating. Tilt alarm with drive & lift cut-out (3.5 deg x 1.5 deg). All motion audible alarm. Lanyard attachment points. Operator horn. Forklift pockets and tie down / lift lugs. Overload sensing system. Half height spring hinged entry gate.
