Engine |
24" - RSN - 3/8" - C85
SKU: 970 49 30‑24
|
28" - RSN - 3/8" - C85
SKU: 970 49 30‑28
|
20" - RSN - 3/8" - C85
SKU: 970 49 30‑30
|
32" - RSN - 3/8" - C85
SKU: 970 49 30‑32
|
20" - RSN - 3/8" - C83
SKU: 970 49 30‑70
|
24" - RSN - 3/8" - C83
SKU: 970 49 30‑74
|
28" - RSN - 3/8" - C83
SKU: 970 49 30‑78
|
32" - RSN - 3/8" - C83
SKU: 970 49 30‑82
|
28" - RSN - 3/8" - H83
SKU: 970 49 30‑88
|
32" - RSN - 3/8" - H83
SKU: 970 49 30‑92
|
36" - RSN - 3/8" - H83
SKU: 970 49 30‑96
|
Chain speed at max power |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
75.5 fts |
Cylinder displacement |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
5.25 cu.inch |
Power output |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
6.9 hp |
Torque, max. |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
5.3 Nm |
Torque, max. at rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
7,800 rpm |
Clutch engagement speed (±120) |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
4,300 rpm |
Electrode gap |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
0.02 in |
Idling speed |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
2,800 rpm |
Ignition module air gap |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
0.01 in |
Maximum power speed |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
9,600 rpm |
Oil pump type |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Adjustable flow, no flow at idle |
Spark Plug |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
NGK CMR6H |
Equipment |
|
|
|
|
|
|
|
|
|
|
|
Recommended bar length, min |
18 in |
18 in |
18 in |
18 in |
18 in |
18 in |
18 in |
18 in |
18 in |
18 in |
18 in |
Pitch |
3/8" |
3/8" |
3/8" |
3/8" |
3/8" |
3/8" |
3/8" |
3/8" |
3/8" |
3/8" |
3/8" |
Recommended bar length, max |
36 in |
36 in |
36 in |
36 in |
36 in |
36 in |
36 in |
36 in |
36 in |
36 in |
36 in |
Chain type |
C85 |
C85 |
C85 |
C85 |
C83 |
C83 |
C83 |
C83 |
H83 |
H83 |
H83 |
Bar length |
60 cm |
70 cm |
50 cm |
81 cm |
50 cm |
60 cm |
70 cm |
81 cm |
70 cm |
81 cm |
90 cm |
Bar length (inch) |
24 in |
28 in |
20 in |
32 in |
20 in |
24 in |
28 in |
32 in |
28 in |
32 in |
36 in |
Sprocket type |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Rim 7 |
Dimensions |
|
|
|
|
|
|
|
|
|
|
|
Weight (excl. cutting equipment) |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
16.5 lbs |
Sound and noise |
|
|
|
|
|
|
|
|
|
|
|
Sound pressure level at operators ear |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
112 dB(A) |
Sound power level, guaranteed (LWA) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
119 dB(A) |
Sound power level, measured |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
118 dB(A) |
Vibration |
|
|
|
|
|
|
|
|
|
|
|
Equivalent vibration level (ahv, eq) rear handle |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
5.9 m/s² |
Equivalent vibration level (ahv, eq) front handle |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
6.7 m/s² |
Lubricant |
|
|
|
|
|
|
|
|
|
|
|
Oil tank volume |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
0.89 US pint |
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Husqvarna 2 stroke or equiv. at 50:1 |
Emission |
|
|
|
|
|
|
|
|
|
|
|
Exhaust emissions (CO2 EU V)
|
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
792 g/kWh |
