SNORKEL 27' ROUGH TERRAIN SCISSOR LIFT
Max. working height
33 ft
Max. platform height
27 ft
Platform size (stowed)
5 ft 2 in x 9 ft 8 in
Platform size (extended)
5 ft 2 in x 13 ft 1 in
Deck extension length
4 ft
Overall length
11 ft
Overall width
5 ft 10 in
Min. height (guardrails folded)
6 ft
Stowed height
8 ft 7 in
Ground clearance
13 in
Platform capacity (SWL)
1,250 lbs
Max. drive height
27 ft
Max. wind speed
28 mph
Max. drive speed (elevated)
0.3 mph
Max. drive speed (stowed)
2.8 mph
Raise / lower time
26 / 30 seconds
Gradeability
35%
Max. outrigger levelling (front to rear)
6°
Max. outrigger levelling (side to side)
10°
Inside turning radius
8 ft 10 in
Outside turning radius
16 ft 3 in
Tires
27 x 10.5 – 15 non-marking foam filled
Controls
Proportional joystick
Drive system
4 wheel drive
Power source
Kubota D-902 water cooled diesel 22.5 hp – Tier 4 Final
Weight
6,172 lbs
The Snorkel S2770RT compact rough terrain diesel scissor lift is lightweight yet powerful. Equipped with robust 4-wheel drive, it makes easy work of rough terrain. Compact dimensions allow the S2770RT to perform outdoor work in confined spaces. Auto level outriggers and a roll-out deck extension also come as standard.
